When the four arms are adjusted to preferred angles, it is recommended to add the
accompanied arrow stickers. This allows for easy realignment and exchanging between
dierent work items.
Payload
The lifting capacity of the VG grippers depends primarily on the following parameters:
•
Vacuum cups
•
Vacuum
•
Air
flow
Vacuum Cups
Choosing the right vacuum cups for your application is essential. The VG grippers come with
common 15, 30 and 40 mm silicone vacuum cups (see table below) which are good for hard
and
flat surfaces, but not good for uneven surfaces and it might leave microscopic traces of
silicone on the workpiece which can cause issues with some types of painting processes
afterwards.
External Diameter [mm] Internal Diameter [mm] Gripping Area [mm2]
15 6 29
HARDWARE SPECIFICATION
209
