Handling
OPTIMUM
MASCHINEN - GERMANY
© 2008
GB
Page 32 Metal belt saw S210G; S275G; S210G Vario; S275G Vario version 1.3.1 4 February 2008
5.7 Liquid cooling system
ATTENTION!
Failure of the pump in the event of a dry
run. The pump is lubricated by the cool-
ing agent. Do not start up the pump
without cooling agent.
Symbol: Cooling pump
Illustr.5-10: Cooling pump
INFORMATION
We recommend that you use a water-soluble and non-pollutant sawing emulsion as a cooling
agent. This can be acquired from authorised distributors.
Make sure to clean up the cooling agent after use.
Respect the environment when disposing of any lubricants and cooling agents.
Follow the manufacturer's disposal instructions.
Turn on the liquid cooling system with
the switch.
Illustr.5-11: Control panel
5.8 Starting the metal belt saw
Start the metal belt saw by pressing the
green button.
Illustr.5-12: Control panel
Switch for cooling
pump
"OFF" button
""ON" button
