3 Assembly
INFORMATION
The metal belt saw comes pre-assembled.
3.1 Parts list
When the machine is delivered, check immediately that the metal belt saw has not been dam-
aged during shipping and that all components are included. Also check that the set screws are
loosened.
• Metal belt saw
• Saw belt
• Liquid cooling system
• Depth stop
•Saw table
• Fitting tools
• Instruction manual
3.2 Storage
ATTENTION!
Improper storage may cause important parts to be damaged or destroyed
.
Store packed or unpacked parts only under the following external conditions. “Exter-
nal conditions“ on page 15
Consult Optimum Maschinen Germany GmbH if the metal belt saw and accessories have to be
stored for a period of over three months or under different external conditions to those given
here.
3.3 Installation and assembly
3.3.1 Requirements of installation site
Organise the workplace around the metal belt saw in accordance with local safety regulations.
“Tension of the saw belt“ on page 22
Operation, maintenance and repair in the work area must not be hindered.
INFORMATION
If a mains plug is fitted on the metal belt saw, it must be accessible.
ATTENTION!
Danger of crushing and overturning.
Proceed with caution during the work described below.
The metal belt saw must be fitted on the machine stand by at least 2 people.
