OPTIMUM
MASCHINEN - GERMANY
Handling
© 2008
GB
Page 334 February 2008 version 1.3.1 S210G; S275G; S210G Vario; S275G Vario Metal belt saw
5.9 Hydraulic feed
Adjust the descent speed of the saw
arch in the feed regulation valve.
Open the shut-off tap.
Illustr.5-13: Hydraulic feed
The belt saw is disconnected automatically once it reaches the end of the run.
Follow the same steps in reverse order to remove the work piece from the vice.
EMPIRICAL RULE!
The finer the tooth spacing and/or the thinner or smaller the work piece, the lower the
feed should be.
Feed regulation valve
Shutt-off tap
