Optimum S210G - Page 46

Ersatzteile - Spare parts - S210G, S275G
OPTIMUM
MASCHINEN - GERMANY
46
S:\Betriebsanleitungen\saws\S210_S275G\S210G_S275G_parts\S210G_S275G_parts.fm
4.2.08
35 Schneckengetriebe Gear 1 S210G 0330021035
35 Schneckengetriebe Gear 1 S275G 0330027535
35-1 Simmerring Getriebe Shaft seal helical gear 1
TC 35/70/10
F542
S210G 0322169
35-1 Simmerring Getriebe Shaft seal helical gear 1
TC 35/70/10
F542
S275G 0322169
35-2 Simmerring Getriebe Shaft seal helical gear 1 25/40/7 S210G 0322180
35-2 Simmerring Getriebe Shaft seal helical gear 1 25/40/7 S275G 0322180
36 Motor Motor 1 S210G 0330021036
36 Motor Motor 1 S275G 0330027536
37 Verkleidungsblech Lining plate 1 S210G 0330021037
37 Verkleidungsblech Lining plate 1 S275G 0330021037
40 Schaltkasten Switch box 1 S210G 0330021040
40 Schaltkasten Switch box 1 S275G 0330021040
41 Abdeckung Cover 1 S210G 0330021041
41 Abdeckung Cover 1 S275G 0330027541
42 Gewindestange Threaded rod 1 S210G 0330021042
42 Gewindestange Threaded rod 1 S275G 0330027542
43 Feder Spring 1 S210G 0330021043
43 Feder Spring 1 S275G 0330027543
44 Handradgriff Hand wheel grip 2 S210G 0330021044
44 Handradgriff Hand wheel grip 2 S275G 0330021044
45 Inbusschraube Allen screw 1 S210G 0330021045
45 Inbusschraube Allen screw 1 S275G 0330021045
46 Nabe Hub 1 S210G 0330021046
46 Nabe Hub 1 S275G 0330021046
47 Bandführungsrolle Un-driven belt guide roller 1 S210G 0330021047
47 Bandführungsrolle Un-driven belt guide roller 1 S275G 0330027547
49 Lager Bearing 2 6004 2Z S210G 0406004.2R
49 Lager Bearing 2 6004 2Z S275G 0406004.2R
50 SägebandHSS Bi-Metall Saw belt 1 10-14 ZPZ S210G 3357515
50 SägebandHSS Bi-Metall Saw belt 1 10-14 ZPZ S275G 3357525
50 SägebandHSS Bi-Metall Saw belt 1 6-10 ZPZ S210G 3357514
50 SägebandHSS Bi-Metall Saw belt 1 6-10 ZPZ S275G 3357524
51 Federring Spring washer 1 S210G 0330021051
51 Federring Spring washer 1 S275G 0330027551
52 Mutter Nut 1 S210G 0330021052
52 Mutter Nut 1 S275G 0330021052
53 Welle Shaft 1 S210G 0330021053
53 Welle Shaft 1 S275G 0330027553
54 Führungsblock Guide block 1 S210G 0330021054
54 Führungsblock Guide block 1 S275G 0330027554
55 Handgriff Handgrip 1 S210G 0330021055
55 Handgriff Handgrip 1 S275G 0330021055
56 Handgriffverlängerung Handgrip extension 1 S210G 0330021056
56 Handgriffverlängerung Handgrip extension 1 S275G 0330021056
57 Spindel Spindle 1 S210G 0330021057
57 Spindel Spindle 1 S275G 0330021057
59 Feder Spring 1 S210G 0330021059
59 Feder Spring 1 S275G 0330021059
60 Spannhebel Tension lever 1 S210G 0330021060
60 Spannhebel Tension lever 1 S275G 0330021060
61 Lager Bearing 1 51106 S210G 04051106.2R
61 Lager Bearing 1 51106 S275G 04051106.2R
62 Lagerabdeckung Bearing cover 1 S210G 0330021062
62 Lagerabdeckung Bearing cover 1 S275G 0330021062
63 Handrad Hand wheel 1 S210G 0330021063
63 Handrad Hand wheel 1 S275G 0330021063
64 Feder Spring 1 S210G 0330021064
64 Feder Spring 1 S275G 0330027564
65 Ösenschraube Eyelet bolt 1 S210G 0330021065
65 Ösenschraueb Eyelet bolt 1 S275G 0330021065
67 Lagerbock Bearing support
1
S210G 0330021067
67 Lagerbock Bearing support S275G 0330027567
68 Bolzen Bolt
1
S210G 0330021068
68 Bolzen Bolt S275G 0330027568
69 Inbusschraube Allen screw
1
S210G 0330021069
69 Inbusschraube Allen screw S275G 0330021069
Pos.
Bezeichnung Designation
Menge Grösse Machine
Artikelnum-
mer
Qty. Size Item no.
