Control central and
paging desk
If you wish to stop the repetition of the message before it
ends, activate contact I1 once again.
Before activating the repeat function, it is necessary to select
the destination zones and/or groups for the message.
Input CONTACT "I2”:
If this is connected to the ground contact, the TALK function
is activated, in the same way as when the TALK key is
pressed on the desk keypad.
This functionality remains active while the contact remains
activated.
Before activating the TALK function, it is necessary to select
the destination zones and/or groups for the message.
Input CONTACT "I3":
If this is connected to the ground contact, the GONG+TALK
function is activated (Pre-announcement tone + Talk), in the
same way as when the GONG+TALK key is pressed on the
desk keypad.
This functionality remains active while the contact remains
activated.
Before activating the GONG+TALK function, it is necessary to select the destination zones and/or groups
for the message.
4.5. Fitting the ETHERCON NE8MC connectors and compatibility with
RJ45
The desk has NE8MC model Ethercon connectors. Four
are pre-fitted on the two interconnection cables
between the desk and the CC-600ETH box and
another two are supplied as accessories for the
connection of the box with the switch.
These connectors reinforce the connection and so it is
highly recommended to fit them.
The table to the right shows the RJ45 brands and
models that are compatible with this connector.
220.9026
220.0210
220.0200
220.0201
