Optimus DC-600ETH - 13 Dimensions; 14 Technical Specifications

DC-600ETH version 1.4
39
Control central and
paging desk
DC-600ETH
13. DIMENSIONS
14. TECHNICAL SPECIFICATIONS
DC-600ETH
Inputs
2 Ethernet and 1 music program input (RCA connectors)
Power supply
24 V DC
Consumption
500 mA
Weight
Desk + junction box + accessories: 2.7 kg
Finishing
Desk: Plastic Bayblend RAL7021
Front polyester adhesive Pantone 447C
Junction box: Black skinplate
MICROPHONE
Capsule
Dynamic
Polar diagram
Unidirectional
Frequency response
150 Hz 8 kHz
Sensitivity
-76dB 3 dB (0 dB = 1 V/microbar at 10,000 Hz)
Output impedance
500 Ohm 30% (at 1 kHz)
Finishing
Aluminium
