optris LS – E2006-01-A
18
Data Logger
The LS has an internal data logger with a maximum capacity of 100 measurement protocols.
Every protocol contains the following values:
Position number [P 00...P 99], object temperature, MAX-, MIN-, AVG- and DIF-value, emissivity, probe temperature (if
connected), material and location name
Storing Data
To store any data the unit must be in the HOLD mode. At first please take your
measurement and after this release the Trigger:
HOLD⇒ V ⇒Disc symbol + next free Pos. [Pxx] ⇒ Λ ⇒INCREASE POS.-NO.
⇒ V ⇒DECREASE POS.-NO.
⇒ I ⇒STORE
1)
⇒HOLD
1)
The storage will be confirmed with a double buzzer tone.
If you pull the Trigger
no storage
will be made and the unit changes to the Measurement mode.
If no button is pressed, also
no storage
will be made and the unit switches off after approx. 30 s.
If the storage mode is started the next free position will automatically be shown.
If you select an occupied position, the P flashes in the upper display.
The storage function can also be executed after recall of the last value [► Recall (Last Value)].
