Data Logger Functions
To download the logger data from the unit please press the Logger -button [Menu: Measurement\ Download
logger data].
All data from the logger will be displayed in an extra window as a table:
Columns in the logger table
Index serial number
Date date of measurement
Time time of measurement
TObj object temperature
TObj Min min. object temperature
TObj Max max. object temperature
TObj Avg average object temperature
TObj Diff. difference between
TObj Min and TObj Max
TInt internal unit temperature
TExt t/c temperature
(if connected)
Hi-Alarm High-Alarm value
Lo-Alarm Low-Alarm value
Eps emissivity
Name material or position name
Logger temperatures, on which the set High-Alarm value has been exceeded, will be shown in the table red
and bold.
Logger temperatures, on which the set Low-Alarm value has been fallen below, will be shown in the table blue
and bold.
