optris LS – E2006-01-A
27
The once selected displays will also appear after a restart of
the software. The size can be changed if you put the mouse
cursor on the line beneath the display and pull it down. The
buttons of the tool bar will also be moved (depending on the
display size).
Diagram Functions
S
TARTING THE
M
EASUREMENT
To start a measurement, please press the Start
button in the tool bar
[Menu: Measurement\ Start].
Control elements of the time axis:
1 Scroll bar
2 Zoom in (increase)
3 Zoom out (decrease)
4 Whole range
5 H: Hold/ C: Continue
