optris LS – E2006-01-A
20
Data Logger Recall
To recall a stored measurement protocol the unit must be set into the Measure mode:
Trigger+ V [while keeping the trigger pressed]⇒Disc symbol flashes⇒P xx [starting with position 00]
To switch between the data logger positions and different displays please proceed as follows:
Upper display Main display Lower display Examples
P -1⇐ V ⇐P xx⇒ Λ ⇒P +1 TObj e a Material and location name e 1
⇑
II e
⇓ ⇑
a MAX e TObj e Emissivity II e 2
⇑ ⇑ ⇓
Λ Trigger+ Λ e
⇓ ⇓
a MAX/ TObj e TObj/ MAX/ MIN/ AVG/ DIF TExt [probe temperature] 3 + 4
1 2 3 4
