Material and Location Names
You can assign a 4-digit alpha numeric description to any data logger position.
This description will be shown in the bottom display and has the following
presetting:
P000 (for position 1) – P099 (for position 100)
In the editing mode you can choose between 20 pre-defined descriptions
(SURF, ENG, ..., GLAS, ..., PVC, etc.). To do this please start the data logger
mode and choose a desired position:
Disc symbol + choosen position [Pxx]⇒ II ⇒description flashes ⇒ Λ ⇒SURF, ..., GLAS, ..., PVC, ...
⇒ V ⇒PVC, ..., GLAS, ..., SURF, ...
⇒ I ⇒SAVE
You can also define own descriptions. The following character set can be used:
[A...Z] [0...9] [-/<>] [empty]
Disc symbol + choosen position [Pxx] ⇒2x II ⇒1. character flashes ⇒ Λ ⇒CHANGE VALUE
⇒ V ⇒CHANGE VALUE
⇒ II ⇒next character flashes ⇒ Λ ⇒CHANGE VALUE
⇒ V ⇒CHANGE VALUE
after input of all characters: ⇒ I ⇒SAVE
