Basic Operation
Batteries
Please do not use old and new batteries together.
Please use only alkaline or rechargeable batteries
[Type: Mignon AA, R6, UM3].
To open the battery compartment gently press the cover lid on the left side of
the handle in direction of the arrow (see picture). Insert the batteries (orientation
as shown inside the compartment) and close the cover lid. Your new
LaserSight is already equipped with batteries, which are protected with a
plastic strip against discharge during the transport (please remove). If the batteries are low the battery symbol
will appear in the display. Please exchange the batteries
immediately if the symbol is flashing.
User interface
1 Precision glass optics
2 Optics toggle switch SF/ CF
3 Tripod mount
4 Trigger
5 Display
6 Up and Down buttons
7 Mode (I and II) buttons
8 Handle and battery compartment
9 USB interface
10 t/c input
optris LS – E2006-01-A
4
