optris LS – E2006-01-A
34
Specification
Technical Data
Temperature range IR: -35…900°C (-30…1650°F)
Temperature range probe: -35…900°C (-30…1650°F)
Temperature unit: °C/ °F (switchable)
Spectral range: 8…14µm
Optical resolution: 75:1 (16mm@1200mm/ 90% energy)
switchable to CF (close focus): 1mm@62mm/ 90% energy
Minimum spot size: 1mm@62mm (CF mode)
Temperature resolution: 0,1°C
Accuracy IR
1)
: ±0,75°C or ±0,75% of reading (whichever is greater)
Accuracy t/c input: ±0,75°C or ±1,0% of reading (whichever is greater)
Repeatability: ±0,5°C or ±0,5% of reading (whichever is greater)
Temperature coefficient
2)
: ±0,05K/K or ±0,05%/K (whichever is greater)
Response time: 150 ms (95% signal)
Display: LCD Flip Display with backlight
(horizontal and vertical viewing directions controlled by position
sensor)
Display backlight: green and alarm colours (red/ blue)
Bar graph display: auto scaling
Laser: <1mW, class II, 630-650 nm
SF: patented crosshair laser
(size of crosshairs = spot size@ any distance)
CF: two point laser (laser dot size = spot size@ focus distance)
