Remove Replaceable Components From Motherboard Assembly
204 Oracle Database Appliance Service Manual • June 2017
■
“Remove Replaceable Components From Motherboard Assembly” on page 204
■
“Install Replaceable Components in Motherboard Assembly” on page 205
Remove Replaceable Components From Motherboard
Assembly
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the replaceable components prior to removing the motherboard
from Oracle Database Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 112.
b.
Remove the server node from the system.
Power is removed from the server node when you remove it from the system. See
“Removing Server Nodes From the System Chassis” on page 113.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 114.
2.
With the exception the SAS expander cable, disconnect and remove all internal
cables from the server node.
Note - To identify the SAS expander cable, see “Install SAS Expander Cable” on page 199.
The cables for the fans, the primary and secondary HBA PCIe cards, and the boot disk
backplane must be removed.
■
Fan power cables
See Remove “Remove Fan Power Cables” on page 190.
■
Primary HBA PCIe card data cables
See “Remove PCIe Card Cables From Primary HBA PCIe Card” on page 193.
■
Secondary HBA PCIe card data cables
See “Remove PCIe Card Cables From Secondary HBA PCIe Card” on page 195.
