Oracle Database Appliance X6-2-HA User Manual

Install Replaceable Components in Motherboard Assembly
AppendixA • Servicing the Oracle Database Appliance Version 1 205
Caution - Equipment damage. The HBA data cables are delicate. Ensure that they are
removed and safely out of the way when servicing the motherboard.
■
Boot disk board cables.
See “Remove Boot Disk Backplane Cables” on page 200.
3.
Remove the following components from the server node.
■
Fan modules
“Remove a Fan Module” on page 126.
■
Boot disk drives
“Remove a Boot Drive” on page 122.
■
Boot disk drive backplane
“Remove Boot Disk Backplane” on page 169.
■
Memory modules (DIMMS)
“Remove Faulty DIMMs” on page 135.
■
PCIe riser and attached PCIe cards
“Remove PCIe Riser From Server Nodes” on page 144.
■
CPUs
“Remove Processor (CPU)” on page 163.
■
Internal primary HBA PCIe card
“Remove Primary HBA PCIe Card From Motherboard” on page 153.
■
Battery
“Remove Battery” on page 157.
Install Replaceable Components in Motherboard Assembly
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes reinstalling the replaceable components removed when replacing the
motherboard in Oracle Database Appliance Version 1.
1.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention Measures” on page 112.
