Install Replaceable Components in Motherboard Assembly
206 Oracle Database Appliance Service Manual • June 2017
2.
Install the following components into the server node.
■
Fan modules
See “Install a Fan Module” on page 127.
■
Boot disk drives
See “Install a Boot Drive” on page 124.
■
Memory modules (DIMMS)
See “Install DIMMs” on page 139.
■
PCIe riser and attached PCIe cards
See “Install PCIe Riser in Server Nodes” on page 145.
■
CPUs
See “Install Processor (CPU)” on page 166.
■
Internal primary HBA PCIe card
See “Install Primary HBA PCIe Card in Motherboard” on page 154.
3.
Reconnect and install the following cables.
■
Fan module power cables.
See “Servicing the Fan Power Cables (FRU)” on page 190.
■
Internal PCIe card data cables.
See “Servicing the PCIe Card Cables (FRU)” on page 192.
Caution - Equipment damage. The disk drive data cables are delicate. Handle them carefully.
■
Boot disk backplane cables.
See “Servicing the Boot Disk Backplane Cables (FRU)” on page 200.
4.
Return the server node to operation.
a.
Install the server node top cover.
See “Installing the Server Node Top Cover” on page 207.
b.
Install the server node into the system.
See “Installing a Server Node Into the System Chassis” on page 208.
c.
Reconnect all external data cables from the PCIe card(s) that are installed in
the PCIe riser.
d.
Power on the server node.
See “Powering On Oracle Database Appliance Version 1” on page 210.
