Install Front Indicator Panel
120 Oracle Database Appliance Service Manual • February 2016
Install Front Indicator Panel
1.
Use the Phillips screw to attach the new indicator panel to the ear bezel [1].
2.
Connect the ribbon cable to the indicator panel [2].
3.
Place the ear bezel on the chassis [3].
4.
Fasten the four Phillips screws inside the drive bays [4].
5.
Fasten the three Phillips screws on the back of the ear bezel [5].
6.
Replace the disk drives in the drive bays [6].
