Oracle Database Appliance User Manual

Enable or Disable Option ROM Settings
Chapter8 • Server Node Basic Input/Output System (BIOS) 167
6.
In the dialog box, do one of the following:
■
Select -Enabled to enable the Option ROM setting.
■
Select -Disabled to disable the Option ROM setting.
7.
Press F10 to save the changes and exit the BIOS Setup Utility.
BIOS Setup Utility Hot Keys
The following table provides a description of the Oracle Database Appliance (original version)
BIOS Setup Utility Oracle ILOM Remote Console keys and the directly attached keyboard
keys, and the corresponding serial connection key combinations.
Oracle ILOM Remote Console Keys Serial Connection Hot Key
Combinations
Function
F1 Ctrl+Q (Press and hold the Control
key and type Q)
Access the BIOS Setup Utility if
there is an error during the boot
process.
F2 Ctrl+E Enter BIOS Setup Utility when the
system has completed the power-on
self-test (POST).
F7 Ctrl+D Discard changes, but do not exit.
F8 Ctrl+P Select the BBS Popup menu, which
allows you to select a boot device.
F9 Ctrl+O Load optimal BIOS defaults.
F10
†
Ctrl+S Save changes and exit.
F12 Ctrl+N Boot the server node from the
network (PXE boot).
†
F10 is not supported on the Oracle ILOM Remote Console; instead, use the arrow keys to navigate to the Exit menu and press Enter.
Accessing the BIOS Setup Utility Menus
You can access Oracle Database Appliance (original version) BIOS Setup Utility screens from
the following interfaces:
■
Use a USB keyboard, mouse, and VGA monitor connected directly to the server node.
■
Use a terminal (or terminal emulator connected to a computer) through the serial port on the
back panel of the server node.

Oracle Database Appliance Specifications

General

Product Type	Database Appliance
Form Factor	Rack-mountable
Storage Type	SSD
RAID Support	RAID 1, RAID 5, RAID 6, RAID 10
Storage Expansion	Yes
Maximum Disk Drives	Varies by model (e.g., 12, 18, 36)
