Remove Boot Disk Backplane
Chapter5 • Servicing FRUs 103
Set 'clear_fault_action' to 'true'
Servicing the Boot Disk Backplane (FRU)
The Oracle Database Appliance (original version) boot disk backplane (BDB) serves as an
interface between the motherboard and the rear-mounted disk drives.
The boot disk backplane is a FRU and can only be replaced by an Oracle-qualified service
technician.
Caution - Equipment damage. These procedures require that you handle components that are
sensitive to static discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow antistatic practices as described in “Performing Electrostatic Discharge
and Antistatic Prevention Measures” on page 34.
This section includes:
■
“Remove Boot Disk Backplane” on page 103
■
“Install Boot Disk Backplane” on page 104
Remove Boot Disk Backplane
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention Measures” on page 34.
b.
Remove the server node from the system.
Power is removed from the server node when you remove it from the system. See
“Removing Server Nodes From the System Chassis” on page 34.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 35.
2.
Unseat the boot disk drives.
See “Remove a Boot Drive” on page 52.
3.
Remove the boot disk backplane.

Oracle Database Appliance Specifications

General

Product Type	Database Appliance
Form Factor	Rack-mountable
Storage Type	SSD
RAID Support	RAID 1, RAID 5, RAID 6, RAID 10
Storage Expansion	Yes
Maximum Disk Drives	Varies by model (e.g., 12, 18, 36)
