Install a Boot Drive
Chapter3 • Servicing CRUs That Do Not Require System Power Off 53
b.
Pull the door open [2].
c.
On the drive you plan to remove, push the storage drive release button to
open the latch [2].
d.
Grasp the latch and open it to a 45 degree angle [2].
e.
Using the latch, slowly pull the drive straight out of the drive slot, not
sideways or vertically [2].
Do not use much force on the latch when removing the drive.
Caution - Equipment damage. Do not use the latch as an ejector. Do not bend it too far to the
right.
Caution - Equipment damage. Close the door after removing a boot drive to prevent
overheating due to improper airflow.
Install a Boot Drive
1.
Determine the drive slot location for the replacement drive.
