Oracle Database Appliance X3-2/X4-2 Status Indicators
14 Oracle Database Appliance Service Manual • February 2016
Callout Indicator/LED: Color State Meaning
1 AC power fault indicator: amber ■ On – Indicates an AC power fault.
■ Off – Normal operation.
2 Power supply status indicator:
green
■ On – The power supply is operating normally.
■ Off – The power supply is unplugged or turned off.
3 Fan fail indicator: amber ■ On – The fan is faulty.
■ Off – Normal operation.
4 DC power fail indicator: amber ■ On – The power supply is faulty.
■ Off – Normal operation.
5 SAS I/O Module status
indicators: green or amber
■ OK – Lights green to indicate normal operation.
■ Service Required – Lights amber to indicate a fault with the I/O
module (top module is 0; bottom module is 1).
6 Reserved This port is reserved for Oracle Service.
7 Network port (reserved) This port is reserved for Oracle Service.
8 Host SAS port activity indicators
(x4 per port): green
Lights green to indicate host SAS link activity.
Oracle Database Appliance X3-2/X4-2 Status Indicators
This section describes the status indicators for Oracle Database Appliance X3-2 and Oracle
Database Appliance X4-2.
■
“Server Node Status Indicators” on page 14
■
“Storage Shelf Status Indicators” on page 15
Server Node Status Indicators
These topics describe Oracle Database Appliance X3-2 and Oracle Database Appliance X4-2
server node status indicators (LEDs).
Note - The links in the following table take you to topics outside of the Oracle Database
Appliance library to the Sun Server X3-2 and Sun Server X4-2 documentation libraries. Use
your browser's Back button to return to the Oracle Database Appliance library.
ODA X3-2 ODA X4-2
Server Node General Status Indicators Server Node General Status Indicators
Server Node Fan Status Indicators Server Node Fan Status Indicators
