Oracle Database Appliance (Original Version) Status Indicators
Chapter1 • Overview of System Status Indicators and LEDs 17
Callout Indicator/LED: Color State Meaning
2 Power supply status indicator:
green
On – The power supply is operating normally.
Off – The power supply is unplugged or turned off.
3 Fan fail indicator: amber On – The fan is faulty.
Off – Normal operation.
4 DC power fail indicator: amber On – The power supply is faulty.
Off – Normal operation.
5 SAS I/O Module status
indicators: green or amber
OK – Lights green to indicate normal operation.
Service Required – Lights amber to indicate a fault with the I/O
module (top module is 0; bottom module is 1).
6 Reserved This port is reserved for Oracle Service.
7 Network port (reserved) This port is reserved for Oracle Service.
8 Host SAS port activity indicators
(x4 per port): green
Lights green to indicate host SAS link activity.
Oracle Database Appliance (Original Version) Status
Indicators
This section describes the status indicators for the original version Oracle Database Appliance.
“Server Node Status Indicators” on page 17
“Server Node Fan Indicators” on page 20
“Storage and Boot Drive Status Indicators” on page 21
“Power Supply Status Indicators” on page 21
“Rear Server Node Status Indicators” on page 22
“Server Node Internal LEDs” on page 24
“Ethernet Port Indicators” on page 25
Server Node Status Indicators
The following table lists and describes the general status indicators on the front and rear panel
of each Oracle Database Appliance (original version) server node.
