Chapter5 • Servicing FRUs 87
5
♦♦♦C H A P T E R  5
Servicing FRUs
The following topics describe how to service field-replaceable units (FRUs) for the Oracle
Database Appliance. You must power down the system and disconnect the AC power cords
from the server before servicing any of these components.
Only Oracle authorized service personnel should service FRU components.
“Servicing Oracle Database Appliance X3-2/X4-2/X5-2 FRUs” on page 87
“Servicing Oracle Database Appliance (Original Version) FRUs” on page 94
Servicing Oracle Database Appliance X3-2/X4-2/X5-2 FRUs
This section describes how to service server node FRUs for Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, and Oracle Database Appliance X5-2. If you have Oracle
Database Appliance (original version), go to “Servicing Oracle Database Appliance (Original
Version) FRUs” on page 94.
Only Oracle authorized service personnel should service FRU components.
Note - Most of the links in the following table take you to instructions outside of the Oracle
Database Appliance library to the Sun Server X3-2, Sun Server X4-2, and Oracle Server X5-2
documentation libraries. Use your browser's Back button to return to the Oracle Database
Appliance library.
ODA X3-2 ODA X4-2 ODA X5-2
FRU Locations FRU Locations FRU Locations
Servicing Processors Servicing Processors Servicing Processors
Servicing the Disk Backplane Servicing the Disk Backplane Servicing the Disk Backplane
Servicing the Front Indicator Module Servicing the Front Indicator Module Servicing the Front Indicator Module
Servicing the Motherboard Servicing the Motherboard Servicing the Motherboard
