Oracle Database Appliance User Manual

Servicing Oracle Database Appliance (Original Version) CRUs
Chapter4 • Servicing CRUs That Require Server Node Power Off 63
Callout Description
1 DDR3 Memory DIMMs (12)
2 PCIe Cards Mounted on PCIe Riser
3 PCIe Riser
4 Internal HBA PCIe Card
5 Battery
Servicing Memory Modules (DIMMs) (CRU)
Each server node in Oracle Database Appliance (original version) is provisioned with twelve
1333 MHz or 1600 MHz DDR3, 8GB dual rank DIMMs, for a total of 96GB.
The server node supports a maximum memory speed of 1333 MHz, even if 1600 MHz DIMMs
are installed.

Oracle Database Appliance Specifications

General

Product Type	Database Appliance
Form Factor	Rack-mountable
Storage Type	SSD
RAID Support	RAID 1, RAID 5, RAID 6, RAID 10
Storage Expansion	Yes
Maximum Disk Drives	Varies by model (e.g., 12, 18, 36)
