Preparing Oracle Database Appliance (Original Version) for
Service
This chapter describes how to prepare Oracle Database Appliance (original version) for
servicing. If you have Oracle Database Appliance X3-2, Oracle Database Appliance X4-2, or
Oracle Database Appliance X5-2, go to “Preparing Oracle Database Appliance X3-2/X4-2/X5-2
for Service” on page 27.
■
“Component Replacement Policy – CRUs and FRUs” on page 28
■
“Safety Information” on page 30
■
“Required Tools ” on page 30
■
“Obtaining the Chassis Serial Number” on page 30
■
“Shutting Down a Server Node and Powering Off the System” on page 31
■
“Performing Electrostatic Discharge and Antistatic Prevention Measures” on page 34
■
“Removing Server Nodes From the System Chassis” on page 34
■
“Removing the Server Node Top Cover” on page 35
■
“Removing the Middle Section of the System Top Cover” on page 36
Component Replacement Policy – CRUs and FRUs
The replaceable components in your Oracle Database Appliance (original version) are
designated as either field-replaceable units (FRUs) or customer-replaceable units (CRUs). Some
can be replaced with the power on, some require the powering off of a server node, and some
require the powering off of the entire system chassis.
■
A part designated as a FRU must be replaced by Oracle-qualified service technician.
