Oracle Database Appliance User Manual

Configure TPM Support in BIOS
Chapter8 • Server Node Basic Input/Output System (BIOS) 163
The updated Trusted Computing screen appears and shows that the Execute TPM Command
setting has changed to Enabled.
8.
Press F10 to save the changes and exit the BIOS Setup Utility.
9.
To verify that TPM support is configured, do the following:
a.
Reboot the server node.
b.
To enter the BIOS Setup Utility, press the F2 key while the system is
performing the power-on self-test (POST).
When BIOS is started, the main BIOS Setup Utility top-level screen appears.
c.
Select Advanced, then select Trusted Computing and press Enter.
The updated Trusted Computing screen appears.

Oracle Database Appliance Specifications

General

Product Type	Database Appliance
Form Factor	Rack-mountable
Storage Type	SSD
RAID Support	RAID 1, RAID 5, RAID 6, RAID 10
Storage Expansion	Yes
Maximum Disk Drives	Varies by model (e.g., 12, 18, 36)
