Replace a Storage Shelf I/O Module
46 Oracle Database Appliance Service Manual • February 2016
Example showing the DE2-24P:
Example showing the DE2-24C:
Callout Description
1 I/O module 1 (top)
2 I/O module 0 (bottom)
