Server Overview
Component Description
CPU Two processors installed on the motherboard assembly.
Memory Eight memory riser modules are supported:
■ Each riser module supports 4 DIMMs for a total of 32 DIMMs.
■ A server using eight riser modules fully populated with 32-GB DIMMs supports a
maximum of 1 TB of system memory.
I/O expansion Eight PCIe Gen3 slots. All slots support x8 PCIe cards, four slots support x16 PCIe cards.
Storage devices For internal storage, the server provides:
■ Six 2.5-inch drive bays, accessible through the front panel.
■ A slot-loading DVD+/-RW drive on the front of the server, below the drive bays.
■ One eUSB module, installed on the motherboard beneath the memory riser modules.
USB ports ■ Two external USB 3.0 ports (rear panel).
■ Two external USB 2.0 ports (front panel).
Video ports Two high-density HD-15 video ports (1 front, 1 rear).
Ethernet ports Four 10GbE 100/1000/10000 Mbps, RJ-45-based ports on the rear panel.
Power supplies Two hot-swappable AC 2060W (N+1).
Cooling fans Six hot-swappable, redundant fans at chassis front (top-loading). Redundant fans in each
power supply.
SP Oracle Integrated Lights Out Manager (Oracle ILOM).
Related Information
■
Server Service
■
Oracle ILOM documentation
■
“Front Panel Components (Installation)” on page 12
■
“Rear Panel Components (Installation)” on page 13
Understanding the Server 11
