Side
Water supply instructions
Place the cup at the cup holder position.
Water comes out 1 second after.
Water is automatically filled into
the set position.
(min : 1 second, max : 10 seconds)
Water comes out from the spittoon 10
seconds after.
(min : 1 second, max : 10 seconds)
Checklist
Water supply should be suspended when
the cup is removed while water is supplied
Drainage should be suspended when the
cup is recognized during drainage
Water supply volume value should be
changed when the water volume is set to
variable water supply resistance
Water drainage volume value should be
changed when the water volume is set to
variable water drainage resistance
Ⅱ Wiring Test
v
Operating status between PCBs (chair operation)
§ Water Supply/Spittoon
『Water Supply Test』
