Osstem Implant K3 - Handpiece Pneumatic Pressure Control

153
Ⅹ Pneumatic control
Handpiece Pneumatic Pressure Control
§ How to adjust pneumatic pressure
• Air pressure of 3.5 bar is recommended for the handpiece.
• Configure the air regulator settings and then the master block settings.
• Configure settings considering the drop in pressure that occurs while the air passes
through the pipe.
Air Regulator
: 5 Bar
Handpiece
Pressure gauge
Master Block
: 4 Bar
