33
Ⅲ K3 UNIT CHAIR Installation
§ Installation precautions #1
1. Level off Doctor Table
As shown in the figure, remove the Table Cover. Adjust the wrench bolts shown in Figure "A" and
"B“ and level off the Doctor Table.
2. Adjust Balance Arm Tension
As shown in the figure, remove the Slide Bar
Cover Cap.
Using a 5mm T-wrench in the "C" area on the
figure, adjust the Balance Arm tension.
DOCTOR TABLE INSTALLATION
『TABLE Installation』
To Next Page
