Osstem Implant K3 - Assemble Cup Dispenser

45
Ⅲ K3 UNIT CHAIR Installation
HANARO CONSOLE INSTALLATION
§ Installation procedures #4
7. Assemble Main Top Body Right
As shown in <Figure 07>, put Main Top Body
Right (G) over the Main Body (A).
8. Assemble Cup Dispenser
As shown in <Figure 08>, put the Cup Dispenser
Body (H) and the Cup Dispenser Cap (I) in the
Main Body (A), in that order.
< Figure 08 >
< Figure 07 >
『 HANARO CONSOLE Installation』
