Ⅲ K3 UNIT CHAIR Installation
CHAIR INSTALLATION
§ Installation precautions #2
3. Chair levelness adjustment
After installing the unit chair, check the
levelness using a level gauge, and balance
the unit chair using the levelness
adjustment bolt shown in <Figure 01>.
4. Chair speed adjustment
Use 5mm T-wrench
『CHAIR Installation』
Chair speed adjustment valve Chair speed adjustment valve
Chair Up
Chair Down Back Down
Back Up
Chair levelness adjustment bolt
