Ⅲ K3 UNIT CHAIR Installation
DENTAL LIGHT INSTALLATION
§ Installation procedures
1. Insert Wire in Light Arm Assembly
As shown in <Figure 10>, pass the wire of Light
Arm Assembly through the Light Pole ① to insert
it in the unit.
2. Assemble Light Arm Assembly
As shown in <Figure 02>, level off the Light Arm
Assembly (A) and put it in the Light Pole ① in the
vertical direction.
< Figure 02 >
< Figure 01 >
1
『DENTAL LIGHT Installation』
