Ⅲ K3 UNIT CHAIR Installation
HANARO CONSOLE INSTALLATION
§ Installation procedures #1
1. Assemble Main Body
As shown in <Figure 01>, put the Support Insert
(B) in the Main Body (A).
2. Assemble Pole Support
As shown in <Figure 02>, put the Support Insert
(B) in the Pole Support (C).
< Figure 02 >
< Figure 01 >
『 HANARO CONSOLE Installation』
