111
Wiring Test
v
Key operation test
§ Doctor Table Membrane Connection Test
ü Connection procedures
- Lift the connector, and detach or
attach the film connection section
- Perform a check on the operation of
each key button
- If any of the membrane keys are pressed
èAll keys do not work è Membrane failure
- Check the error window
KEY operation test
