Ⅱ Wiring Test

Operating status between PCBs (chair operation)

§ DC5V Table PCB power check

『TABLE PCB』

Table PCB Checklist

①

Check the LED (table PCB power) operation

②

Check the fuse for main PCB on the right side

Spec. : 1.6A

Fuse for

Table PCB

DC 5V LED

Power supply to table PCB

IF DC 5V LED is OFF
