Ⅲ K3 UNIT CHAIR Installation
MONITOR ARM INSTALLATION
§ Installation procedures #4
7. Insert Monitor Arm Wire
As shown in <Figure 07>, pass the wire of
Monitor Arm Assembly (F) through the Light Pole
(B) to insert it into the unit.
8. Assemble Pole Arm Body Cover
As shown in <Figure 08>, assemble the Pole Arm
Body Cover (E).
< Figure 08 >
< Figure 07 >
『MONITOR ARM Installation』
