MATE3s Screens
900-0209-01-00 Rev A
49
Figure 43 Wiring Diagram for Diversion Load and AUX Wiring
Photovoltaic (PV) Array
Diversion Relay
Charge Controller
DC
Disconnect
Panel
Inverter
Battery Bank
Diversion Load
Wind Generator
PV PV
PV
N/C
Common
Coil
AUX
Ground
PV+ PV– BAT– BAT+
Inverter Negative
DC Disconnect
DC Disconnect
DC Disconnect
Shunt
Terminal Bus Bar
(
Ne
g
ative
)
Terminal Bus Bar
(Ground)
Terminal Bus Bar
(
Positive
)
RTS
Inverter
DC Disconnect
Inverter Positive
12 Vdc
12 Vdc
12 Vdc
12 Vdc
NOTE:
See page 48
for important
requirements
when using
the mode
Diversion:
Solid St.
