Oval 50 - 16 Outline Dimensions

B-149-4N-E
29
Unit: mm
b1： ×1 1/h
b2： ×10 s1/sis
MIT
×10 ml
MODE
RESET
MODE
MODE
RESET
φ130
φ130
L
137
8
B
D
F
B
D
E
F
E
CABLE ENTRY G1/2
(Output signal type)
Heating tube
Cooling tube
(1) 10K TYPE DIMENSIONS
Size Flange Rating L (face-to-face) B (overall) D E F Approx. Weight
50
JIS 10K RF 200
296.8 43
φ
96 211.8
w/cool tube 14kg
w/heat tube 13kg
ASME, JPI, 150 RF 198
Size Flange Rating L (face-to-face) B (overall) D E F Approx. Weight
52
JIS 10K RF 200
353.3 47
□
106 264.3
w/cool tube 17kg
w/heat tube 16kg
ASME 150 RF 200
53
JIS 10K RF 200
376.8 59.5
□
106 275.3
w/cool tube 18kg
w/heat tube 17kg
ASME 150 RF 200
Size Flange Rating L (face-to-face) B (overall) D E F Approx. Weight
55
JIS 10K RF 230
371.3 71
φ
163
258.3
w/cool tube 23kg
w/heat tube 22kg
ASME 150 RF 233
56
JIS 10K RF 250
391.3
76
φ
193
273.3
w/cool tube 27kg
w/heat tube 26kg
ASME 150 RF 258
Unit: mm
b1： ×1 1/h
b2： ×10 s1/sis
MIT
×10 ml
MODE
RESET
MODE
MODE
RESET
B
D
φ130
L
8
137
B
D
E
φ130
G
CABLE ENTRY G1/2
Heating tube
Cooling tube
E
F
G
F
(Output signal type)
(1) 10K TYPE DIMENSIONS
Size Flange Rating L (face-to-face) B (overall) D E F G Approx. Weight
57
JIS 10K RF 350
424.3 87
φ
260 295.3 171.5
w/cool tube 43kg
w/heat tube 42kg
ASME 150 RF 357
NOTE: For outline dimensions of jacketed meters and pipeline connections dimentions, see the approval drawing.
16. OUTLINE DIMENSIONS
