17. PRODUCT CODE EXPLANATION
●
Main code (Meter model: 50, 52, 53, 55, 56, 57)
① ② ③
Model
L U S ULTRA OVAL (integral type) Single case all stainless
L U J ULTRA OVAL (single standard jacket) Element: stainless steel
④ ⑤
Capacity (Nominal Diameter)
5 0 20mm (3/4") ND (Big)
5 2 25mm (1") ND (Big)
5 3 25mm (1") ND (Big)
5 5 40mm (1·1/2") ND (Big)
5 6 50mm (2") ND (Big)
5 7 50mm (2") ND (Big)
⑥
Nominal diameter
4 Nominal diameter (Big) integral type
⑦
—
⑧
Fluid category
L Liquid
⑨
Temp. category
0 60℃ and lower
1 Over 60℃ up to 120℃
2 Over 120℃ up to 200℃ w/Cooling n
3 Over 200℃ and up to 260℃ w/Cooling n
5 Sudden temp. change (120℃ and lower)
6 Low temp. (−30℃ and over and below −10℃) Max. temp. 60℃ w/Heating tube
⑩
Major material
C SCS14 (SUS316)
S SCS16 (SUS316L)
Z Special
⑪ ⑫
Process connection
J 1 JIS10K RF
J B JIS16K RF
J 2 JIS20K RF
J 3 JIS30K RF
A 1 ASME150 RF
A 3 ASME300 RF
P 1 JPI150 RF
P 3 JPI300 RF
D 1 DIN10 RF
D B DIN16 RF
D 3 DIN25 RF
Z 9 Special
⑬
—
⑭
Explosion-proof
0 Non-explosionproof
2 TIIS
8 KCs
⑮
Ex-proof temp. class
0 Non-explosionproof
4 T4
⑧−⑥⑤④③②① ⑯⑮⑭−⑫⑪⑩⑨ − −㉑⑳ ㉔㉓ ㉖㉕⑲⑱
Model
Fluid category
Capacity (Nominal Diameter)
Nominal diameter
Register
Regulations
Power supply
Bearing
Special
Seal material
Viscosity category
Version
Output
Explosion-proof
Ex-proof temp. class
Temp. category
Process connection
Major material
Main code
/ / / Additional code
⑯
Regulations
0 Standard
G High Pressure Gas Safety Act (Approved product) w/Material test certicate
H High Pressure Gas Safety Act (Individual test)
w/Material test certicate
(Designed on PO issued)
J
High Pressure Gas Safety Act
(Completion inspection)
w/Material test certicate
L Gas Business Act (Approved product)
w/Material test certicate
(Designed on PO issued)
M Gas Business Act w/Material test certicate
Q Electricity Business Act (Certicate required)
w/Material test certicate
(Designed on PO issued)
R Electricity Business Act w/Material test certicate
T Fire Service Act w/Material test certicate
A Nuclear power
w/Material test certicate
(Designed on PO issued)
F w/Material test certicate
Z Special
⑰
—
⑱
Register
H Smart Type ULTRA register
⑲
Power supply
0 External power supply (standard)
⑳
Output
A Analog
D Current pulse
M Current pulse + open collector pulse
W Open collector pulse + analog
Z Special
󰼼
Version
A Version code: A
󰽇
—
󰽈
Bearing
0 Standard (carbon bearing)
2 Standard (strong alkali carbon)
8 Polymerizing liquid (carbon bearing)
5 Highly corrosive liquid (ceramic bearing)
6 Hydrogen peroxide solution (ceramic bearing)
7 Highly corrosive polymerizing liquid (ceramic bearing)
󰽉
Viscosity category
2 Below 1000mPa·s R3 sintered rotor
3 1000mPa·s and over R3 special cut sintered rotor
5
Below 200mPa·s
Cut rotor
(sintered rotors inapplicable)
6
200mPa·s and over
Special cut cut rotor
(sintered rotors inapplicable)
7
Below 1000mPa·s
R3 cut rotor
(sintered rotors inapplicable)
8
1000mPa·s and over
R3 special cut cut rotor
(sintered rotors inapplicable)
󰽊
Seal material
F O-ring (FPM), gasket (T#1120)
C O-ring (IIR), gasket (T#1120)
T O-ring (PTFE), gasket (V7020)
P O-ring (PTFE), gasket (V7035)
Z Special
󰽋
Special
0 Standard
Z Special
