Owon HDS series - 5. Input Connections; 5.1 Input Connections

OWON HDS Series Handheld DSO & DMM 5-Input Connections
5.Input Connections
5.1 Input Connections
See the following figure 2:
figure 2
Description:
1. The power adapter is supplied for AC power supply and battery recharging.
2. Multimeter test lead.
3. Multimeter input jacks, including three circular banana jacks and tow square jacks.
The three circular jacks are used for voltage, current and resistance inputs, while
the two square jacks are used for capacitance inputs.
7
