OWON HDS Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
the horizontal axis and CH2 is on the vertical axis; when the oscilloscope is under the sampling
mode in which no trigger is found, the data appear in light spots.
Operations for various control keys are shown as below:
■ The CH1 VOL and CH1 ZERO for CH1 are used to set the horizontal scale and position.
■ The CH2 VOL and CH2 ZERO for CH2 are used to set the vertical scale and position
continuously.
The following functions do not work in the XY display mode:
■ Reference or digital value waveform
■ Cursor
■ Time base control
■ Trigger control
8.8 Waveform Saving Setups
The oscilloscope can save 4 waveforms, which can be displayed on the screen with the present
waveform. The recalled waveform saved in the memory cannot be adjusted,
The waveform saving /recalling menu is described in the following list.
Function
menu
Setups Description
Source
CH1
CH2
MATH
Source of wave form to be saved.
Available sources:CH1,CH2,MATH
WAVE
A , B
C , D
Location where selected waveform to be saved or recalled.
Save Action to save selected waveform to selected location.
CH(X)
X=A,B,C,D
OFF
ON
Turn Display on/off for selected and stored waveform.
To save a waveform on CH1 in address A, do the following:
1. Press the MENU key and the function menu appears at the right of the screen.
2. Press the MENU ▲ or MENU ▼ key to select the Waveform Saving. Four items
selectable are displayed at the bottom of the screen.
3. Press the F1 key to select the signal source CH1.
4. Press the F2 key to select the address A.
5. Press the F3 key to save the waveform on CHI1 in address A.
To display the saved waveform on the screen, do the following:
４７
To Next Page
