OWON HDS Series Handheld DSO & DMM 10-Appendix
10.Appendix
10.1 Appendix a Specifications
10.1.1 Oscilloscope
Only if another instructions are provided, are all technical specifications applicable to the probe
with the 10X attenuation switch setting and the HDS series digital type oscilloscope. In order to be
up to these specifications, the oscilloscope should meet the following requirement.
■ The instrument should operate continuously for more than 30 minutes under the specified
operating temperature.
■ If the operating temperature range of variation is up to or larger than 5 Celsius degrees, the
system function menu must be opened to make the system perform a “self- calibration”
procedure.
Except those specifications marked with the word Typical, all specifications can be up to.
Sampling
Sampling modes
Normal sampling
Peak detection
Average value
Sampling rate
100 MSa/s -----HDS1022M
250 MSa/s -----HDS2062M
Input
Input coupling DC, AC,Groud
Input impedance 1MΩ±2% connected in parallel with 20pF±5pF
Probe attenuation coefficient 1X, 10X, 100X, 1000X
Max. Input voltage 400V (peak)
Channel delay time（typical） 150ps
Horizontal
Sampling rate range
10S/s～100MS/s -----HDS1022M
10S/s～250MS/s -----HDS2062M
Waveform interpolation （sin x）/x
Record length 6K points on each channel
Scanning speed range
（S/div）
5ns/div～100s/div, stepping in the “1-2.5-5” mode. ----HDS1022M
5ns/div～100s/div, stepping in the “1-2-5” mode. -----HDS2062M
Sampling rate and relay ±100ppm(any time interval which is equal to or larger than 1ms)
59
