Owon HDS series User Manual

OWON HDS Series Handheld DSO & DMM 10-Appendix
Measurement
Cursor measurement Voltage difference (△V) and time difference (△T) between cursors
Auto measurement
Peak-to-peak value, average value, root mean square value, frequency ,
period ， Vmax, Vmin ， Vtop, Vbase, Vamp, Overshoot, Preshoot,
RiseTime, Fall Time, +Width, -Width, +Duty, -Duty, DelayA
B and
DelayA
B .
Probe
1X position 10X position
Bandwidth Up to 6 MHz (DC) Up to full bandwidth (DC)
Attenuation rate 1: 1 10: 1
Compensation range 15pf～35pf
Input resistance 1MΩ±2％ 10MΩ±2％
Input impendence 85pf～115pf 14.5pf～17.5pf
Input voltage ＜200 V DC+Peak AC ＜600 V DC+Peak AC
10.1.2 Meter
Voltage (VDC)
Input Impedance: 10MΩ.
Max. Input Voltage: 1000V (DC or AC peak-to-peak value)
Range Accuracy Resolution
400.0mv 100uV
4.000V 1mV
40.00V 10mV
400.0V
±1%±1 digit
100mV
Voltage (VAC)
Input Impedance: 10MΩ.
Max. Input Voltage: 750V(AC, virtual value)
Frequency range: from 40Hz to 400Hz.
Display: Virtual value of the sine wave
Range Accuracy Resolution
4.000V 1mV
40.00V 10mV
400.0V
±1%±3 digits
100mV
61

Owon HDS series Specifications

General

Channels	2
Bandwidth	Up to 100 MHz
Multimeter Functions	Voltage, Current, Resistance, Capacitance
Resistance Measurement Range	400Ω ~ 40MΩ
Power Supply	Lithium Battery
Connectivity	USB
Battery Life	About 6 hours
Weight	Approx. 500 g
Duty Cycle Range	0.1% to 99.9%
Data Storage	Internal memory
Voltage Measurement Range	400mV ~ 1000V
Current Measurement Range	0.1 μA to 10 A
