OWON HDS Series Handheld DSO & DMM 10-Appendix
Direct Current (DC)
Range Accuracy Resolution
40.00mA ±1%±1 digit 10uA
400.0mA ±1.5%±1 digit 100uA
20A ±3%±3 digits 10mA
Alternating Current (AC)
Range Accuracy Resolution
40.00mA ±1.5%±3 digit 10uA
400.0mA ±2%±1 digit 100uA
20A ±5%±3 digits 10mA
Resistance
Range Accuracy Resolution
400.0 Ω ±1%±3 digits 0.1Ω
4.000KΩ 1Ω
40.00KΩ 10Ω
400.0KΩ 100Ω
4.000MΩ
±1%±1 digit
1KΩ
40.00MΩ ±1.5%±3 digits 10KΩ
Capacitance
Range Accuracy Resolution
51.20nF 10pF
512.0nF 100pF
5.120uF 1nF
51.20uF 10nF
100uF
±3%±3 digits
100nF
Diode
Voltage reading: 0 V ～1.5 V.
On-off Test
You can a beep sound when the on-resistance is less than 50Ω.
10.1.3 General Specifications
Basic parameter
Mechanical dimension 18 cm×11.5cm×4cm
Weight 645 g
Power consumption ＜ 6 W
62
