OWON HDS Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
figure 46: Dot Style
figure 47: Vector Style
8.7.2 Persistence
With Persistence function selected, the displayed saved original data gradually decay in color and
the new data are bright in color; with infinite persistence mode selected, the recorded points will
be kept on the screen till the controlled value is changed.
8.7.3 XY Mode
This mode is only applicable to CH1 and CH2. With the XY mode selected, CH1 is displayed on
４６

Owon HDS series Specifications

General

Channels	2
Bandwidth	Up to 100 MHz
Multimeter Functions	Voltage, Current, Resistance, Capacitance
Resistance Measurement Range	400Ω ~ 40MΩ
Power Supply	Lithium Battery
Connectivity	USB
Battery Life	About 6 hours
Weight	Approx. 500 g
Duty Cycle Range	0.1% to 99.9%
Data Storage	Internal memory
Voltage Measurement Range	400mV ~ 1000V
Current Measurement Range	0.1 μA to 10 A
