OWON HDS Series Handheld DSO & DMM 8-Advanced Function of Oscilloscope
8.10 Making Automatic Measurements
The oscilloscope can perform 20 types automatic measurements such as frequency, cycle, average
value, peak-to-peak value , root mean square value,
Vmax, Vmin, Vtop, Vbase, Vamp,
Overshoot, Preshoot, RiseTime, Fall Time, +Width, -Width, +Duty, -Duty,
DelayA B and DelayA B . And gives two kinds of measurement results simultaneously
on the screen.
The function menu for automatic measurements is described in the following list.
Function menu Settings Description
Freq
CH1
CH2
Measure the frequency of CH1
Measure the frequency of CH2
Period
CH1
CH2
Measure the Period of CH1.
Measure the Period of CH2
Mean
CH1
CH2
Measure the average value of CHI.
Measure the average value of CH2.
Peak-Peak
CH1
CH2
Measure the peak-to-peak value of CH1.
Measure the peak-to-peak value of CH2.
Cyc RMS
CH1
CH2
Measure root mean square (RMS) value of CH1.
Measure root mean square (RMS) value of CH2.
Vmax
CH1
CH2
Measure the
Vmax of CH1
Measure the
Vmax of CH2
Vmin
CH1
CH2
Measure the
Vmin of CH1
Measure the
Vmin of CH2
Vtop
CH1
CH2
Measure the
Vtop of CH1
Measure the
Vtop of CH2
Vbase
CH1
CH2
Measure the
Vbase of CH1
Measure the Vbase of CH2
Vamp
CH1
CH2
Measure the
Vamp of CH1
Measure the
Vamp of CH2
Overshoot
CH1
CH2
Measure the
Overshoot of CH1
Measure the
Overshoot of CH2
Preshoot
CH1
CH2
Measure the
Preshoot of CH1
Measure the
Preshoot of CH2
RiseTime
CH1
CH2
Measure the
RiseTime of CH1
Measure the
RiseTime of CH2
Fall Time
CH1
CH2
Measure the
Fall Time of CH1
Measure the
Fall Time of CH2
+Width
CH1
CH2
Measure the
+Width of CH1
Measure the
+Width of CH2
-Width
CH1
CH2
Measure the
-Width of CH1
Measure the -Width of CH2
+Duty
CH1
Measure the +Duty of CH1
４９

Owon HDS series Specifications

General

Channels	2
Bandwidth	Up to 100 MHz
Multimeter Functions	Voltage, Current, Resistance, Capacitance
Resistance Measurement Range	400Ω ~ 40MΩ
Power Supply	Lithium Battery
Connectivity	USB
Battery Life	About 6 hours
Weight	Approx. 500 g
Duty Cycle Range	0.1% to 99.9%
Data Storage	Internal memory
Voltage Measurement Range	400mV ~ 1000V
Current Measurement Range	0.1 μA to 10 A
