Owon HDS series User Manual

OWON HDS Series Handheld DSO & DMM 10-Appendix
Display type 3.8" color liquid crystal display
Display resolution 320 (horizontal) ×240 (vertical) pixels
Display color 4096 colors
Power Adapter
Power supply
100-240 V AC 50/60Hz
Power output 8.5 VDC
Current output 1500 mA
Battery:7.4V built-in Li-ion Battery
Working environment
Temperature
Operation
Used battery 0 to 50 °C(32 to 122 °F)
Power adapter 0 to 40 °C(32 to 104 °F)
Storage. -20 to +60 °C(-4 to +140 °F)
Temperature
Operation:
0 to 10 °C(32 to 50 °F) no condensation
10 to 30 °C(50 to 86 °F) 95 %
30 to 40 °C(86 to 104 °F) 75 %
40 to 50 °C(104 to 122 °F) 45 %
storage
-20 to +60 °C(-4 to +140 °F). no condensation
10.2 Appendix B: Maintenance and Cleaning
10.2.1 Common Maintenance
Do not store or place the instrument in locations where the liquid crystal display (LCD) may be
directly exposed to the sunshine for a long time.
Be careful: Do not make spraying agent, liquid and solvent touch with probes to avoid the
instrument or probe being damaged.
63

Owon HDS series Specifications

General

Channels	2
Bandwidth	Up to 100 MHz
Multimeter Functions	Voltage, Current, Resistance, Capacitance
Resistance Measurement Range	400Ω ~ 40MΩ
Power Supply	Lithium Battery
Connectivity	USB
Battery Life	About 6 hours
Weight	Approx. 500 g
Duty Cycle Range	0.1% to 99.9%
Data Storage	Internal memory
Voltage Measurement Range	400mV ~ 1000V
Current Measurement Range	0.1 μA to 10 A
